CPU

QCA9563+9886

Flash

16M

DDR2

128M

2.4G frequency

5.150GHz～5.850GHz

2.4G WIFI protocol

802.11 a / n /ac

Antenna

5.8G directional panel antenna, gain：12dBi

Max Rate

900Mbps

5G TX Power

802.11a

54M

21±2dBm

6M

24±2dBm

802.11n HT20

MCS7

20±2dBm

MCS0

23±2dBm

802.11n HT40

MCS7

19±2dBm

MCS0

22±2dBm

802.11AC

MCS9

18±2dBm

MCS0

21±2dBm

5G Receiving Sensitivity

802.11a

54M

-72dBm

6M

-92dBm

802.11n HT20

MCS7

-70dBm

MCS0

-89dBm

802.11n HT40

MCS7

-68dBm

MCS0

-87dBm

802.11AC

MCS9

-58dBm

MCS0

-85dBm

5G EVM

802.11a_54M: ≤-25 dB；802.11n_MCS7: ≤-28 dB；802.11AC_MCS9:≤-32dB

ppm

±20ppm

WAN

1*10/1000M WAN, support 24V passive POE

LAN

1*10/1000M LAN

Power

PoE 48V  0.5A，DC 12V  1A

Max Power Consumption

< 10W

Reset

Long press for 10 seconds to restore the factory default configuration, and short press for 1 second to initiate pairing

Switch button

Choose AP/ Repeater working mode

Indicators

SYS, WAN, LAN, 5G WIFI, signal*4

Dimension

168mm*86mm*39mm

Weight

0.5kg

Temperature

Working: -20°C to 55°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing)

IP Grade

IP65

ESD

Air:±8K, Touch:±4K

Electrical Surge

Common Mode: 2K, Differential Mode: 1K
