CPU

AR9344

Flash

16MB

DDR

64MB

5G frequency

5.150GHz～5.850GHz

5G WIFI protocol

802.11 a/ n

Max rate

300Mbps

Antenna

Internal 15dBi directional panel antenna

5G TX Power

802.11a

54M

22±2dBm

6M

23±2dBm

802.11n HT20

MCS7

21±2dBm

MCS0

23±2dBm

802.11n HT40

MCS7

20±2dBm

MCS0

23±2dBm

5G Receiving Sensitivity

802.11a

54M

-70dBm

6M

-83dBm

802.11n HT20

MCS7

-67dBm

MCS0

-83dBm

802.11n HT40

MCS7

-64dBm

MCS0

-83dBm

5G EVM

802.11a_54M: ≤-25 dB；802.11n_MCS7: ≤-28 dB；

ppm

±20ppm

WAN

1*10/100 WAN, support 24V POE

LAN

1*10/100 LAN

Power

PoE 24V, DC 12~24V

Max Power Consumption

<8W

Reset

Press 2-5 seconds for pairing, 10seconds for factory reseting.

Indicators

SYS, WAN, LAN, 5G WIFI, Signal*4

Dimension

168mm*86mm*42.5mm

Weight

0.28kg

Temperature

Working: -20°C to 55°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing)

IP Grade

IP65

ESD

Air:±8K, Touch:±6K

Electrical Surge

Common Mode: 2K, Differential Mode: 1K
