Standard

802.11ax/ac/b/g/n

Flash

SPI NOR 16MB

Memory

DDR3 256MB

2.4G Frequency

2.4GHz - 2.484GHz

2.4G Wi-Fi standard

802.11b/g/n/ac/ax

5.8G Frequency

5150~5850MHz

5.8G Wi-Fi Standard

802.11 a/n/ac/ax

Interface

1 * 10/100 /1000 RJ45 WAN Port

1 * 10/100 /1000 RJ45 LAN Port

1 * Reset button, press 10 seconds to revert to default setting

Data Rate

1800Mbps

End Users

120+

RF Power

≤18dBm

PoE

48V (IEEE 802.3af/at)

LED light

Sys and WiFi, WAN, LAN

Power Consumption

≤ 15W

Size

303mmX180mmX87mm

Working Mode

Gateway, AP

Wireless Functions

Multiple SSID functions: 2.4GHz: 4; 5.8GHz: 4.

Support SSID hidden

Support seamless roaming, 802.11kvr standard.

Support 5G Prior for a faster Ethernet.

Wireless Security: Open, WPA, WPA2PSK_TKIPAES, WAP2_EAP, WAP3

Support MAC filter

Support Wi-Fi time on/off to save energy

Support client isolation to improve the wireless stability

Support RF power adjustable, adjust the RF power based on environment.

Support user quantity limited, Max 64 users to access each band.

Networking Function

VLAN settings

Cloud access support in gateway mode

Device Management

Back-up the configuration

Restore the configuration

Reset to factory default

Reboot the device: including time reboot or reboot immediately

Admin management password modify

Firmware upgrade

System log

Support firmware GUI web management, AC controller management, remote management and cloud management

Protocols

IPv4
