Product model

AP 1200G

CPU

QCA9563+ QCA9886+ QCA8337

Flash

8MB

DDR2

Built-in, 64MB

2.4G frequency

2.4GHz – 2.484GHz

2.4G WIFI Standard

802.11 b / g / n

5G frequency

5.150GHz～5.850GHz

5G WIFI Standard

802.11 a/ n / ac

External dual-frequency antenna

22.4GHz / 5GHz omnidirectional dual-frequency antennas, each gain: 5 dBi

top speed

2.4G provides a maximum access rate of 300Mbps, and 5G to 866Mbps

And 2.4G wireless power

802.11b

11M

23±2dBm

1M

24±2dBm

802.11g

54M

22±2dBm

6M

23±2dBm

802.11n HT20

MCS7

20±2dBm

MCS0

23±2dBm

802.11n HT40

MCS7

20±2dBm

MCS0

23±2dBm

5G wireless power

802.11a

54M

19±2dBm

6M

21±2dBm

802.11n HT20

MCS7

17±2dBm

MCS0

21±2dBm

802.11n HT40

MCS7

17±2dBm

MCS0

21±2dBm

802.11ac HT80

MCS9

16±2dBm

MCS0

18±2dBm

2.4G reception sensitivity

802.11b

11M

-83dBm

1M

-94dBm

802.11g

54M

-70dBm

6M

-88dBm

802.11n HT20

MCS7

-68dBm

MCS0

-86dBm

802.11n HT40

MCS7

-66dBm

MCS0

-84dBm

The 5G reception sensitivity

802.11a

54M

-70dBm

6M

-88dBm

802.11n HT20

MCS7

-68dBm

MCS0

-86dBm

802.11n HT40

MCS7

-66dBm

MCS0

-84dBm

802.11ac HT80

MCS9

-56dBm

MCS0

-83dBm

2.4G EVM

802.11b：≤-10 dB ；802.11g: ≤-25 dB ；802.11n: ≤-28 dB

5G EVM

802.11a: ≤-25dB ；802.11n: ≤-28 dB ；802.11ac: ≤-32 dB

frequency deviation (ppm)

±20ppm

joggle (WAN)

110 / 100 / 1000M adaptive WAN port, supporting 48 VPOE

joggle (LAN)

110 / 100 / 1000M adaptive LAN port

key

Set key (press 6-10 seconds to restore factory default configuration)

Status indicator light

PWR lamp, WAN port lamp, LAN port lamp, 2.4G lamp, 5.8G lamp

DC

12V /1A DC

POE

802.3at

maximum power dissipation

< 9W

Product feet

196mm*86mm*40mm

weight

0.4kg

work environment

Normal operating temperature: -30°C to 55°C; storage temperature: -40°C to 70°C; humidity: 5%~95% (no condensation)

levels of protection

IP65

ESD

Air discharge + / -8K, contact discharge + / -6K

surge

Co-mode 6K and difference mode 4K

Wireless AP download rate, wireless AP upload rate, and runtime

Equipment information, equipment description, Intranet information, and WIFI information

Support mode

Gateway mode: the device is connected to the WAN network through the WAN port and connected to the Internet using static IP, DHCP or PPPOE

Relay mode: In this mode, the device overrides wireless network signals to other clients or devices and connects to other routers using the WAN

AP mode: Devices cover wireless network signals over other clients and devices, and use Ethernet to connect to other routers for WAN access

Wireless function

SSID broadcasting

SSID quantity: 4(2.4GHz) + 4 (5GHz), supporting Chinese SSID

Hide the SSID functionality

Wireless encryption: OPEN, WPA / WPA2PSK-TKIPAES, WPA3PSK-TKIPAES

Wireless MAC address filtering: support whitelist

Spectrum navigation (5G is preferred)

WiFi is turned off

User isolation: isolation between wireless networks and AP internal isolation

Emission power setting

Limited number of wireless clients

QoS：WMM

Network function

Connection mode: static address, obtained from the management server, obtained from the gateway

DHCP server: either built-in DHCP server or external DHCP server

Cloud platform server

Firewall function

PPPOE function: support PPPOE dialing function

device management

Backup Configuration Information

Restore configuration information

factory data reset

The boot includes timing restart and immediate restart

firmware upgrade

Time management includes the system display time and time synchronization

system log

Fat and thin AP switching function
