Model	WB5acL3-Ex
CPU	QCA9563+QCA9882+QCA8334
Flash	SPI NOR 16MB
DDR	DDR2-64MB
5G frequency	5.150GHz～5.850GHz
5G WIFI protocol	802.11 a / n /ac
Max rate	900Mbps
Antenna	Internal 15dBi directional panel antenna
5G TX Power	802.11a	54M	23±2dBm	6M	26±2dBm
	802.11n HT20	MCS7	22±2dBm	MCS0	26±2dBm
	802.11n HT40	MCS7	22±2dBm	MCS0	26±2dBm
	802.11ac VHT20	MCS9	21±2dBm	MCS0	26±2dBm
5G Receiving Sensitivity	802.11ac VHT40	MCS9	21±2dBm	MCS0	26±2dBm
	802.11ac VHT80	MCS9	21±2dBm	MCS0	26±2dBm
	802.11a	54M	-75dBm	6M	-92dBm
	802.11n HT20	MCS7	-72dBm	MCS0	-90dBm
5G EVM	802.11a_54M: ≤-25 dB；802.11n_MCS7: ≤-28 dB；802.11AC_MCS9:≤-32dB
ppm	±20ppm
WAN	1*10/100/1000M WAN, support 24V POE
LAN	1*10/100/1000M LAN
Power	PoE 24V, DC 12~24V
Max Power Consumption	<10W
Reset	Press 2-5 seconds for pairing, 10seconds for factory reseting.
Switch button	Set Master/ Slave working mode
Indicators	SYS, WAN, LAN, Signal*5
Dimension	168mm86mm42.5mm
Weight	0.28kg
Temperature	Working: -40°C to 70°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing)
IP Grade	IP65
ESD	Air:±8K, Touch:±6K
Electrical Surge	Common Mode: 4K, Differential Mode: 2K
