Data Sheet |
Model | WB 5-DT 501 |
CPU | MT7628DAN+MT7613AE |
Flash | 8MB |
DDR | 64MB |
5GHz Frequency | 5.150GHz~5.850GHz |
5GHz Standard | 802.11 a / n /ac |
Rate | 867Mbps |
Antenna | 5.8G Hz directional plate antenna, gain: 8 dBi |
5GHz Power | 802.11a | 54M | 17±2dBm | 6M | 19±2dBm |
802.11n HT20 | MCS7 | 16±2dBm | MCS0 | 18±2dBm |
802.11n HT40 | MCS7 | 16±2dBm | MCS0 | 18±2dBm |
802.11ac VHT20 | MCS9 | 16±2dBm | MCS0 | 18±2dBm |
802.11ac VHT40 | MCS9 | 15±2dBm | MCS0 | 17±2dBm |
802.11ac VHT80 | MCS9 | 15±2dBm | MCS0 | 17±2dBm |
5GHz Sensitivity | 802.11a | 54M | -75dBm | 6M | -92dBm |
802.11n HT20 | MCS7 | -71dBm | MCS0 | -89dBm |
802.11n HT40 | MCS7 | -68dBm | MCS0 | -86dBm |
802.11ac VHT20 | MCS9 | -64dBm | MCS0 | -87dBm |
802.11ac VHT40 | MCS9 | -59dBm | MCS0 | -84dBm |
802.11ac VHT80 | MCS9 | -56dBm | MCS0 | -81dBm |
5GHz EVM | 802.11a_54M: ≤-25 dB;802.11n_MCS7: ≤-28 dB;802.11ac _MCS9:≤-32dB |
PPM | ±20ppm |
WAN | 1*10 / 100M adaptive WAN port, support 12V non-standard POE power supply |
LAN | 1*10 / 100M adaptive LAN port |
Power Supply | PoE 12V,DC 12V |
Power Consumption | < 5W |
Reset | Press it for 10 seconds to restore the factory default configuration, short press 1 second to initiate the pairing |
Switch | Set the Master with the switch |
Status indicator light | SYS Led, WAN port Led, LAN port Led, 5G WIFI Led, signal Led 4 |
Product size | 168×86×39mm |
Weight | 0.5kg |
Working environment | Normal operating temperature: -20°C to 55°C; storage temperature: -40°C to 70°C; humidity: 5%~95% (no condensation) |
Levels of protection | IP65 |
ESD | Air discharge + / -8K, contact discharge + / -6K |
Surge | Common mode 2K, difference mode 1K |
