Flash

Nor32MB(Reserved), Nand 128MB

DDR4

512MB×1

Antenna

2.4G: 2*4dBi ; 5G: 2*4dBi

2.4GHz frequency

2.4GHz ~ 2.484GHz

2.4GHz WIFI protocol

802.11 b / g / n / ax / be

5GHz frequency

5.150GHz～5.850GHz

5GHz WIFI protocol

802.11 a / n / ac / ax / be

Mac rate

2.4GHz: 688Mbps, 5GHz: 2882Mbps

2.4GHz EVM

802.11b: ≤-10 dB；802.11g: ≤-25 dB；802.11n: ≤-28dB；802.11ax: ≤-35 dB; 802.11be: ≤-38 dB

5GHz EVM

802.11a: ≤-25 dB ；802.11n: ≤-28 dB ；802.11ac: ≤-32 dB;  802.11ax: ≤-35 dB, 802.11be: ≤-38 dB

ppm

±20ppm

WAN

1*10/100/1000/2500Mbps WAN, support 802.3at

LAN

1*10/100/1000Mbps LAN

Button

reset

Power supply

PoE 802.3at，DC2.0 12V/2A

Power consumption

<24W

Size

198mm × 198mm × 32mm

Weight

0.9kg

Environment

Operating temperature-10°C to 40°C；Storage temperature: -40°C to 70°C；humidity：5％～95％（No condensation）
