Model | AX840 |
Flash | SPI NOR 8MB |
DDR3 | 512MB*1 |
Nand Flash | 128MB |
2.4G RF | QCN5022-2.4G external FEM |
5.8G RF | QCN5052-5.8G external FEM |
2.4G Frequency | 2.4GHz – 2.484GHz |
2.4G Protocol | 802.11 b / g / n /ax |
5G Frequency | 5.150GHz~5.850GHz |
5G Protocol | 802.11 a / n / ac /ax |
Antenna | 4*2.4G/5.8G dual band: 3 dBi+ |
Data Rate | 2.4G 574Mbps MIMO 2*2,5G 2402Mbps MIMO 2*2 |
2.4G TX Power | 802.11b | 11M | 23±2dBm | 1M | 23±2dBm |
802.11g | 54M | 23±2dBm | 6M | 23±2dBm |
802.11n HT20 | MCS7 | 22±2dBm | MCS0 | 23±2dBm |
802.11n HT40 | MCS7 | 21±2dBm | MCS0 | 22±2dBm |
802.11ax HE20 | MCS11 | 20±2dBm | MCS0 | 21±2dBm |
802.11ax HE40 | MCS11 | 19±2dBm | MCS0 | 20±2dBm |
5G TX Power | 802.11a | 54M | 23±2dBm | 6M | 23±2dBm |
802.11n HT20 | MCS7 | 22±2dBm | MCS0 | 22±2dBm |
802.11n HT40 | MCS7 | 21±2dBm | MCS0 | 22±2dBm |
802.11ac VHT20 | MCS9 | 21±2dBm | MCS0 | 22±2dBm |
802.11ac VHT40 | MCS9 | 20±2dBm | MCS0 | 21±2dBm |
802.11ac VHT80 | MCS9 | 19±2dBm | MCS0 | 20±2dBm |
802.11ax HE20 | MCS11 | 20±2dBm | MCS0 | 21±2dBm |
802.11ax HE40 | MCS11 | 19±2dBm | MCS0 | 20±2dBm |
802.11ax HE80 | MCS11 | 18±2dBm | MCS0 | 19±2dBm |
2.4G Receiving Sensitivity | 802.11b | 11M | -90dBm | 1M | -98dBm |
802.11g | 54M | -77dBm | 6M | -93dBm |
802.11n HT20 | MCS7 | -72dBm | MCS0 | -92dBm |
802.11n HT40 | MCS7 | -71dBm | MCS0 | -90dBm |
802.11ax HE20 | MCS11 | -63dBm | MCS0 | -93dBm |
802.11ax HE40 | MCS11 | -60dBm | MCS0 | -91dBm |
5G Receiving Sensitivity | 802.11a | 54M | -77dBm | 6M | -95dBm |
802.11n HT20 | MCS7 | -75dBm | MCS0 | -93dBm |
802.11n HT40 | MCS7 | -72dBm | MCS0 | -91dBm |
802.11ac VHT20 | MCS7 | -74dBm | MCS0 | -93dBm |
802.11ac VHT40 | MCS7 | -72dBm | MCS0 | -91dBm |
802.11ac VHT80 | MCS9 | -62dBm | MCS0 | -88dBm |
802.11ax HE20 | MCS11 | -63dBm | MCS0 | -93dBm |
802.11ax HE40 | MCS11 | -60dBm | MCS0 | -90dBm |
802.11ax HE80 | MCS11 | -56dBm | MCS0 | -87dBm |
2.4G EVM | 802.11b: ≤-10 dB ;802.11g: ≤-25 dB ;802.11n: ≤-28dB ; 802.11ax: ≤-35 dB |
5G EVM | 802.11a: ≤-25 dB ;802.11n: ≤-28 dB ;802.11ac: ≤-32 dB; 802.11ax: ≤-35 dB |
ppm | ±20ppm |
WAN | 1*10/100/1000M RJ45, support 48V PoE |
LAN | 1*10/100/1000M RJ45 |
Reset | Reset to factory settings by pressing 6-10 seconds |
Indicators | WAN, LAN, tricolor LED(sys-red, 2.4G-green, 5.8G-blue) |
Power | DC2.0 12V 2A,PoE 802.3at |
Max Power Consumption | < 14W |
Dimension | 198mm×198mm×42.5mm |
Weight | 0.9kg |
Temperature | Working: -20°C to 55°C;Storage: -40°C to 70°C;Humidity: 5%~95%(Non-Condensing) |
ESD | Air:±8K, Touch:±4K |
Electrical Surge | Common Mode: 2K, Differential Mode: 1K |
