Model	WB5nL8
CPU	AR9344
Flash	16MB
DDR	64MB
5G frequency	5.150GHz～5.850GHz
5G WIFI protocol	802.11 a / n
Max rate	300Mbps
Antenna	Internal 18dBi directional panel antenna
5G TX Power	802.11a	54M	22±2dBm	6M	23±2dBm
	802.11n HT20	MCS7	21±2dBm	MCS0	23±2dBm
	802.11n HT40	MCS7	20±2dBm	MCS0	23±2dBm
5G Receiving Sensitivity	802.11a	54M	-70dBm	6M	-83dBm
	802.11n HT20	MCS7	-67dBm	MCS0	-83dBm
	802.11n HT40	MCS7	-64dBm	MCS0	-83dBm
5G EVM	802.11a_54M: ≤-25 dB；802.11n_MCS7: ≤-28 dB；
ppm	±20ppm
WAN	1*10/100 WAN, support 24V POE
LAN	1*10/100 LAN
Power	PoE 24V，DC 12~24V
Max Power Consumption	<8W
Reset	Press 2-5 seconds for pairing, 10seconds for factory reseting.
Indicators	SYS, WAN, LAN, 5G WIFI, Signal*4
Dimension	268mm115mm45mm
Weight	0.48kg
Temperature	Working: -20°C to 55°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing)
IP Grade	IP65
ESD	Air:±8K, Touch:±6K
Electrical Surge	Common Mode: 2K, Differential Mode: 1K
