CPU

MT7628

FLASH

8MB

SDRAM

64MB

DC-DC

12V  0.5A

Name

Details

LAN

2*10/100MBase-T LAN, support IEEE 802.3/802.3u auto-negotiation

WAN/LAN

1*10/100MBase-T WAN/LAN, support IEEE 802.3/802.3u auto-negotiation;

WIFI Antenna

5dBi external antenna

RESET

Press it 10 seconds, Reset to factory default

LED Light

WAN, LAN, Wi-Fi, System

RF Power

802.11b

11M

17±2dBm

1M

19±2dBm

802.11g

54M

16±2dBm

6M

18±2dBm

802.11n HT20

MCS7

15±2dBm

MCS0

17±2dBm

802.11n HT40

MCS7

15±2dBm

MCS0

17±2dBm

Receive Sensitivity

802.11b

11M

-85dBm

1M

-94dBm

802.11g

54M

-72dBm

6M

-90dBm

802.11n HT20

MCS7

-70dBm

MCS0

-88dBm

802.11n HT40

MCS7

-68dBm

MCS0

-86dBm

EVM

802.11b: ≤-10dB ; 802.11g: ≤-25 dB ; 802.11n: ≤-28 dB

PPM

±20ppm

Channel

1～13, Support auto channel

Standard

802.11b/g/n

Bandwidth

HT20, HT20/HT40

Security

Open System, Shared key, WPA-Personal, WPA2-Personal, WPA-Auto-Personal, WPA-Enterprise(Radius), WPA2-Enterprise(Radius), WPA-Auto-Enterprise(Radius), Radius with 802.1x

RF Power Adjustable

Support

Name

Content

Working Temperature

-30℃ ～ +55℃

Max Working Temperature

-40℃ ～ +85℃ (Throughput some decrease)

Storage Temperature

-40℃ ～ +70℃

Humidity

5％～95％ (No Condensation)

Name

Content

Wi-Fi

Support Auto Channal, Guest SSID, SSID hide, Wireless MAC filter, white and black list

Net

PPPoE, Automatic IP, Static IP, L2TP, PPTP

Support VPN server and VPN client: PPTP, L2TP and OpenVPN

Support AP+Client

Firewall

Support NAT, URL Filter, MAC Filter and Network Service Filter

Support DoS attack protection, SYN flood attack

WAN PING,SSH, HTTP Access

Other functions

NTP and account setup; Port forwarding，Virtual Server，Watchdog，DMZ，DDNS
